Machining and hardware fitting centres for fixed and opening window parts
Materials
- Wood
Applications
- Automated centres for work on wooden window parts
- Cutting, drilling and grooving
- Fitting hardware
Allowable part dimensions:
- Maximum section 180 x 180 mm
- Length from 250 to 5,000 mm
- Numerically controlled centre for work on window parts
- Modular construction, work on 5 faces, possible to add a large number of spindles, for a large variety of work
- Drilling and/or milling on ends and edges for mechanical assembly, or pivot pin holes,
- Cuts and grooves for lock plates, casement bolts, drain slots, including fast drains,
- Fitting of lock plates, hinge-sockets or hinge pins, casement bolt fastening,
- High efficiency, great execution speed, accuracy
- Rate approximately 2 to 4 parts / minute
- Accuracy +/- 0.2 mm
- Allows the processing of large daily volumes, even with very small, customised manufacturing batches
- Centre can be used as a unit or in a line combining several specialised machines
- Automatic programming post-processor with batch file and or 2/3D model import as option
- The FLEXWIN range is available in several models depending on applications
